Q5 - How do I determine whether a USB-C ethernet adapter is compatible?
👇 Find the answer below 👇
Q6 - How do I connect my Android Phone to Ethernet?
Q7 - How do I install a USB C Ethernet Adapter on Windows 10?
Q8 - How do I use USB C to Ethernet Adapter with my MBP?
Q9 - Will this work with Samsung A7 (2017), android v8.0.0?
Q10 - I cannot get the adapter to work, what am I suppose to do?
Q11 - Can it works with Nintendo Switch?
👇 Find the answer below 👇
FREQUENTLY ASKED QUESTIONS on USB C to Ethernet Adapter
The USB-C to Ethernet Adapter is designed to work with the computers and smart devices that have USB-C ports that supports data (most of them should be USB 3.2 or USB 3.1, some of the phone may only get USB 2.0 speed).
This lets you connect to a network using a wired Ethernet cable.
YES, the product names can be difference. You heard one of the followings: USB Type C to Ethernet Adapter, or USB C to Ethernet adapter, or RJ45 to USB C Adapter, or LAN to USB-C Adapter, things like that.
They all indicate a product that is male USB-C in one end and female Ethernet is on the other end. This item can lets you connect to a network using a wired Ethernet cable on your USB C device which supports data.
Since the USB-C connectors and cables connect to both hosts and devices, replacing various electrical connectors including USB-B and USB-A, HDMI, DisplayPort, and 3.5 mm audio cables and connectors, which contains the Ethernet protocol.
NO.
In a word, USB C port may not supply video out, but Thunderbolt 3 must carry video signals.
-
USB-C (formally known as USB Type-C) is a 24-pin USB connector systemwith a rotationally symmetrical connector. A device with a Type-C connector does not necessarily implement USB, USB Power Delivery, or any Alternate Mode. It was published by the USB Implementers Forum (USB-IF).
--src: Wikipedia
-
Thunderbolt 3 is a hardware interfacedeveloped by Intel.
It shares USB-C connectors with USB, and can require special "active" cables for maximum performance for cable lengths over 0.5 meters. Which definitely supports PCIe 3.0 and other protocols, including DisplayPort 1.2 (allowing for 4K resolutions at 60 Hz).
Thunderbolt 3 has up to 15 watts of power delivery on copper cables and no power delivery capability on optical cables. Also using USB-C on copper cables, it can incorporate USB Power Delivery, allowing the ports to source or sink up to 100 watts of power.
--src: Wikipedia
The adapter will compatible with devices which supply OTG function.
USB On-The-Go (USB OTG or just OTG) is a specification first used in late 2001 that allows USB devices, such as tablets or smartphones, to act as a host, allowing other USB devices, such as USB flash drives, digital cameras, mice or keyboards, to be attached to them.
Use of USB OTG allows those devices to switch back and forth between the roles of host and device. A mobile phone may read from removable media as the host device, but present itself as a USB Mass Storage Device when connected to a host computer.
--src: Wikipedia
-
However, if you want to enjoy the fast speed up to 1 Gbps/2.5 Gbps, you need to confirm the followings:
1. Make sure your Internet environment supports 1 Gbps/2.5 Gbps speed Ethernet. (make sure router, switch, hub, or modem meets the requirements)
2. Make sure your host device supports 1 Gbps/2.5Gbps speeds.
3. Make sure your Ethernet Cable connects with the adapter is above CAT 6.
4. Make sure your network connection is active.
New Owner Frequently Asked Questions
first-time use ethernet adapter
Things to prepare: · USB Type-C to RJ45 Adapter, · RJ45 Cable/internet cable · Router (with Internet)
1. Plug the Rj45 cable to the router.
2. Connect the Rj45 cable to the adapter.
3. Connect the adapter to your phone (with USB C Port that supply OTG).
4. Now check the notification and if you see the "Ethernet cable connected" on your phone, then set up the configuration. 4.1. If not, you have to go to Setting -> Connections -> More connections settings -> Ethernet -> Configure Ethernet device. Before connecting the device, you have to configure, otherwise, you can not figure the device's IP address. Recommend choosing the DHCP, with auto-config -> None.
5. Then enable the Ethernet. (Don't forget to turn off your mobile data.)
6. Next, check the indicators on the adapter if it is blinking.
Finally, you are good to go.
· Plug the USB-C connector on the adapter into the USB-C port on your USB-C device.
· Take an Ethernet cable that’s plugged into a router, switch, hub, or modem, and then plug the other end into the Ethernet jack on the adapter.
· To check your Ethernet connection, on your USB C device, select the Network icon on the lower right side of the taskbar.
· In the list of networks, you should see the name of the Ethernet network with the word Connected underneath.
